| Zoom
in on the fun |
| |
•
3 x zoom versatility with immediate response. The PDR-M5 brings
you advanced digital quality and the joy of moving pictures and
the joy of moving images.
•
Optical 3 x zoom
•
Four shots per second continuous shooting. Excellant image quality
with 5-mode flash.
|
|
|
Release
your creativity with one shot per second performance and 3 x zoom.
|
| We're
redefining digital clarity with a 2.14-million-pixel CCD. |
| |
The
high resolution lens, high-speed, high-precision auto focus and
advanced program auto exposure of the PDR-M5 ensure that images
are received in pristine condition before being recorded in UXGA
format (1600x1200 pixels). Recording is then done via a 1/2-inch
2.14 million-pixel charge coupled device (CCD). The result is a
high level of expression and color reproduction with a sharpness
and clarity comparable to that attained by conventional 35mm photography.
SVGA format (800 x 600 pixels) is also available in order to allow
the easy download of images for computers of use on the internet.
Compression
settings to suit your needs.
Whether
you choose to use UXGA or SVGA, the shoot can be further improved
by choosing one of three compression settings. Normal for standard
shooting requirements, Fine, in cases where the emphasis lies
in image quality and Basic, for when quantity of shooting is more
important.
|
|
| 3
x zoom, infinite possibilities. |
| |
The
PDR-M5 stands out from the crowd with the addition of an optical
3 x zoom lens equivalent to a 40-120 mm lens and digital capability
of 2 x zoom*. Along
with wide angle and telephoto settings at the touch of a single
button, the PDR-M5 helps you push the boundaries of digital creativity.
* Use of digital 2 x zoom provides images
of 800 x 600 pixels.
|
|
| 120
seconds* of moving images, recording and playback |
| |
Sometimes
a still shot just isn't enough. That's why the Toshiba PDR-M5
is capable of the recording and playback of up to 120 seconds
of action. Simply select the recorded image playback. Reverse
playback, 2 x speed forward and reverse playback, and compatabillity
with QuickTime 4.0 are just some of the special functions.
* Based on Half size (160 x 120 pixels).
**Recorded images are stored in AVI file format (codec: Motion
JPEG).
|
|
| Four
frames per second. |
| |
Time
intervals of less than one second* between shots and four frames
per second continuous shooting in UXGA format deliver a pleasing
level of spontaneity and a wealth of photo opportunities.
*Following focus lock the PDR-M4 can activite
shutter release and be prepared for the next release in less than
one second. (With flash and preview switched off. Subject to shooting
conditions.) |
|
| A
wealth of shooting functions and convenient features. |
| |
Closer
Control through Manual Options.
Get
creative with a range of settings, including white balance adjustment,
exposure compensation and manual aperture control (AUTO/F3.5/F7.6).
A
Wide Range of Modes.
The
new high-sensitivity mode gives you the choice of speed equivalents
from ISO 100 to ISO 400. Other features include extended exposure
shooting, monochrome shooting, multi-function flash shooting.
A stand-alone erase button allows the simple deletion of unwanted
images.
USB
connectivity for fast downloading on personal computers.
Images are easily download through advanced USB connectivity*
and serial connection via RS-232C/RS-422 cable.
*Compatible with pre-installed Windows*
98/AT, New Power Macintosh G3 and iMac computers.
| |
Windows |
Macintosh |
| CPU |
i486
or higher processor |
Power
Macintosh, New Power Macintosh G3, iMac (Not applicable for
68K Macintosh) |
| OS |
Windows
98/95/NT 4.0 |
Mac
OS 8.1 or higher |
| Memory |
16
MB min |
16
MB min (32 MB min recommended) |
| Free
space on hard disk |
20
MB min* |
For
installation: 8 MB
For software operation: 60 MB* |
| Color
monitor |
256
or more colors (640 x 480 dot min) |
| CD-ROM |
Required |
The
Freedom to Experiment with Filters.
Because
the PDR-M5 can be equipped with the optional adapter ring (PDR-ARM5),
it's easy to incorporate standard 52mm lens filters or a converter
lens.
Speedy
Playback With a Choice of Modes.
2.5X/5X
zoom playback, 9-frame multi playback and Slide Show playback
functions give you versatility and it is also possible to copy
images and increase compression without the need for computer
attachment. Images can also be displayed on normal TV sets
|
|
| Specifications |
| |
| CCD
Sensor |
1/2-inch
CCD with 2.14 million square pixels |
| Resolution |
1600
x 1200 / 800 x 600 selectable Movie:320 x 240 / 160 x 120
selectable |
| Interface |
USB,
Serial (RS-232C and RS-422), Video output |
| File
Format |
JPEG,
Still image: Exif ver. 2.1, DCF Movie: AVI (Motion-JPEG)
|
| Storage
Media |
3.3V
SmartMedia (2-32MB) Upgradeable to 128MB by firmware |
| Firmware |
Fully
upgradeable |
| Lens |
F3.5-F5.0/F7.6-F11,
f=7.4mm – 22mm (35mm equivalent: 40mm–120mm) |
| Focusing
Range |
90cm
- infinity. Macro: 25cm to 90cm |
| Zoom |
3
x optical, 2 x digital, 2.5x / 5x playback |
| LCD
Monitor |
1.8
inch amorphous silicon TFT (122,320 pixels) |
| View
Finder |
Real
image zoom finder |
| Power
Source |
Re-chargeable
lithium-ion battery, AC power adapter |
| Dimensions |
130
(W) x 78 (H) x 70 (D) mm Weight:320g (excl battery) |
| LCD
Play Mode |
Normal,
16 image-multi, 2.5 x zoom, slideshow. |
| 5-Mode
Falsh |
Auto,
red-eye reduction, fill-in, off, slow synchro |
| Mode
Dial |
Set
up, PC download, off, auto record, manual record, playback
|
| Control
Buttons |
Menu,
Self-timer, picture quality, flash mode, macro, erase/format,
LCD display mode, Zoom |
| Recording
modes |
1
shot, burst shot (UXGA: max 4 frames, SVGA: max 16 frames)
multi-shot (16 images per frame), extended exposure shot
(1 sec/2 sec/4 sec/8 sec, selectable) movie (max. 120 sec) |
| Include
Accessories |
Rechargeable
llithium-ion battery, AC power adapter, SmartMedia card
(8 MB), Neck Strap, Serial cable (Win, Mac) Video cable,
USB cable, CD-ROM, Lens cap |
| Optional
Accessories |
Quick
battery charger (PDR-CGI) Litium-ion battery (PDR-BT1) 52mm
filter ring adapter (PDR-ARM5) |
